3604/20 100
Active3M Electronic Specialty
CBL RIBN 20COND 0.025 WHITE 100'
3604/20 100
Active3M Electronic Specialty
CBL RIBN 20COND 0.025 WHITE 100'
Description
General part information
3604/20 100
CBL RIBN 20COND 0.025 WHITE 100'
Technical Specifications
Parameters and characteristics for this part
| Specification | 3604/20 100 |
|---|---|
| Cable Type | Flat Cable |
| Conductor Strand | Solid |
| Jacket (Insulation) Material | Fluorinated Ethylene-Propylene (FEP) |
| Jacket Color | White |
| Length | 100 ft |
| Number of Conductors | 20 |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Pitch | 0.025 in |
| Ratings | 20726, UL, Style |
| Ribbon Thickness | 0.024 in |
| Ribbon Width | 0.5 in |
| Shielding | Unshielded |
| Voltage | 150 V |
| Wire Gauge | 30 AWG |
