110-A-111/03

Active

WECO Electrical Connectors Inc.

PLUG PLUG-IN SCREW 3POS 3.5MM PI

Search across all available documentation for this part.

Active

WECO Electrical Connectors Inc.

PLUG PLUG-IN SCREW 3POS 3.5MM PI

Technical Specifications

Parameters and characteristics for this part

Specification	110-A-111/03

Color	Gray
Contact Material	Copper Alloy
Contact Mating Finish	Tin
Current - UL	8 A
Housing Material	Polyamide (PA), Nylon
Insulation Height	0.43 in
Insulation Height	10.92 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Levels	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Pitch [x]	3.5 mm
Pitch [x]	0.138 in
Positions Per Level	3
Screw Size	M2
Termination Style	Screw - Rising Cage Clamp
Torque - Screw	0.2 Nm
Torque - Screw	1.7 Lb-In
Type	Plug, Female Sockets
Voltage - UL	300 V
Wire Gauge or Range - AWG [Max]	30 AWG
Wire Gauge or Range - AWG [Min]	16 AWG
Wire Gauge or Range - mm²	1.5 mm²
Wire Strip Length	6 mm

PLUG PLUG-IN SCREW 3POS 3.5MM PI

Part	Color	Housing Material	Insulation Height	Insulation Height	Material Flammability Rating	Screw Size	Type	Torque - Screw	Torque - Screw	Pitch [x]	Pitch [x]	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Wire Strip Length	Contact Material	Voltage - UL	Current - UL	Number of Levels	Termination Style	Mounting Type	Contact Mating Finish	Positions Per Level	Wire Gauge or Range - mm²
WECO Electrical Connectors Inc. 110-A-111/03	Gray	Polyamide (PA), Nylon	0.43 in	10.92 mm	UL94 V-0	M2	Plug, Female Sockets	0.2 Nm	1.7 Lb-In	3.5 mm	0.138 in	30 AWG	16 AWG	-40 °C	105 ░C	6 mm	Copper Alloy	300 V	8 A	1	Screw - Rising Cage Clamp	Free Hanging (In-Line)	Tin	3	1.5 mm²

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Terminal Block Plug, Female Sockets 0.138" (3.50mm) 180° Free Hanging (In-Line)
