1702199

Active

Phoenix Contact

FIXED TERMINAL BLOCKS MKDSN 2.5/ 6-BK

Search across all available documentation for this part.

Active

Phoenix Contact

FIXED TERMINAL BLOCKS MKDSN 2.5/ 6-BK

Technical Specifications

Parameters and characteristics commom to parts in this series

Fixed Terminal Blocks 4P 5.08mm 90DEG

Part	Color	Wire Termination	Mating Orientation	Pitch [x]	Pitch [x]	Features	Current	Number of Levels	Voltage	Positions Per Level	Torque - Screw [Max]	Torque - Screw [Max]	Torque - Screw [Min]	Torque - Screw [Min]	Screw Thread	Housing Material	Wire Gauge [Max]	Wire Gauge [Min]	Mounting Type
Phoenix Contact 1888700	Green	Screw - Rising Cage Clamp	Horizontal with Board	0.2 in	5.08 mm	Interlocking (Side)	20 A	1	300 V	4	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	M3	Polyamide (PA), Nylon	30 AWG	12 AWG	Through Hole
Phoenix Contact 1702199	Black	Screw - Rising Cage Clamp	Horizontal with Board	0.197 in	5 mm		20 A	1	300 V	6	0.6 Nm	5.3 Lb-In	4.4 Lb-In	0.5 Nm	M3		30 AWG	12 AWG	Through Hole

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Fixed Terminal Blocks 4P 5.08mm 90DEG

Technical documentation and resources

No documents available
