31392118
ActiveMETZ CONNECT USA Inc.
SHROUDED HEADER, RIGHT ANGLE, FL
31392118
ActiveMETZ CONNECT USA Inc.
SHROUDED HEADER, RIGHT ANGLE, FL
Description
General part information
31392118
18 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.150" (3.81mm) 90°, Right Angle Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 31392118 |
|---|---|
| Color | Black |
| Contact Material | Copper Alloy |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.138 in |
| Current - UL | 8 A |
| Features | Mating Flange |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Housing Material | Nylon 6/6, Polyamide, PA66 |
| Insulation Height | 0.272 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 18 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.15 in |
| Positions Per Level | 18 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - UL | 300 V |
