Description
General part information
AZ9143-08F
Clamp Ipp Tvs Diode Surface Mount DFN3810P9E
Technical Specifications
Parameters and characteristics for this part
| Specification | AZ9143-08F |
|---|---|
| Grade | Automotive |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 9-UDFN |
| Package Name | DFN3810P9E |
| Power Line Protection | No |
| Qualification | AEC-Q101 |
| Type | Zener |
| Unidirectional Channels | 8 |
| Voltage - Breakdown (Min) | 4.5 V |
| Voltage - Reverse Standoff (Max) | 3.3 V |
