Description
General part information
1105880
16.40' (5.00m) Power Cord Black IEC 62196-3 (Type 1) To Cable
Technical Specifications
Parameters and characteristics for this part
| Specification | 1105880 |
|---|---|
| 1st Connector | IEC 62196-3 (Type 1) |
| 2nd Connector | Cable |
| Approval Agency Marking | cURus |
| Approved Countries | United States, Canada |
| Color | Black |
| Conductor Types | Signal, Power |
| Current Rating Options | 2A, 40A |
| Features | Electric Vehicles, Charging, Electric Vehicles Charging (EV Charger) |
| Length | 16.4 ft |
| Number of Conductors - Power | 3 |
| Number of Conductors - Signal | 2 |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -30 °C |
| Shielding | Unshielded |
| Style | Leads, Male Plug |
| Voltage Rating (AC) | 30 VAC |
| Voltage Rating (DC) | 1000 VDC |
| Wire Gauge | 18 AWG, 10 AWG |
