Description
General part information
ALC80D221BB250
CAP ALUMINUM LYTIC 220UF 250V 20% (25 X 30MM) SNAP-IN 10MM 0.796 OHM 1.17A 6000H 105°C BAG
Technical Specifications
Parameters and characteristics for this part
| Specification | ALC80D221BB250 |
|---|---|
| Applications | General Purpose |
| Capacitance | 220 µF |
| ESR (Equivalent Series Resistance) | 796 mOhm |
| Height - Seated (Max) | 1.26 in |
| Impedance | 469 mOhms |
| Lead Spacing | 0.394 in |
| Lifetime | 6000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can - Snap-In, Radial |
| Polarization | Polar |
| Ripple Current | 1.17 A, 2.7 A |
| Size / Dimension Diameter | 0.984 in |
| Tolerance | 20 % |
| Voltage - Rated | 250 V |
