Specification	8Y48072007

ESR (Equivalent Series Resistance)	80 Ohm
Frequency	48 MHz
Height - Seated (Max)	0.022 in, 0.02 in
Load Capacitance	8 pF
Mounting Type	Surface Mount
Operating Mode	Fundamental
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-20 °C
Package / Case	4-SMD, No Lead
Package Length	2 mm
Package Name	4-SMD
Package Width	1.6 mm
Size / Dimension Length	0.079 in
Size / Dimension Width	0.063 in
Type	MHz Crystal
