Description
General part information
KAWS-2405TEL
Isolated Module DC DC Converter 1 Output 5V 6A 18V - 72V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | KAWS-2405TEL |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 6 A |
| Efficiency | 84 % |
| Features | Adjustable Output, Remote On/Off |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 71 °C |
| Operating Temperature (Min) | -40 °C |
| Package Leads | 6 Leads |
| Package Name | 8-DIP Module |
| Power (Watts) | 30 W |
| Size / Dimension Height | 0.43 in |
| Size / Dimension Length | 2 in |
| Size / Dimension Width | 2 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 72 V |
| Voltage - Input (Min) | 18 V |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 5 V |
