CT310LS-ID8
ActiveAllegro MicroSystems
2D ANGULAR SENSOR, DFN-8 PACKAGE
Deep-Dive with AI
Search across all available documentation for this part.
CT310LS-ID8
ActiveAllegro MicroSystems
2D ANGULAR SENSOR, DFN-8 PACKAGE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CT310LS-ID8 |
|---|---|
| Actuator Type | External Magnet, Not Included |
| For Measuring | Rotary, Angle |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Output | Analog Voltage |
| Output Signal | Sine, Cosine |
| Package / Case | 8-XFDFN Exposed Pad |
| Supplier Device Package | 8-DFN (2x2) |
| Technology | Magnetoresistive |
| Termination Style | Gull Wing |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 1 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.60 | |
| 5 | $ 2.19 | |||
| 10 | $ 2.04 | |||
| 25 | $ 1.85 | |||
| 50 | $ 1.72 | |||
| 100 | $ 1.60 | |||
| 500 | $ 1.35 | |||
| 1000 | $ 1.25 | |||
| Digi-Reel® | 1 | $ 2.60 | ||
| 5 | $ 2.19 | |||
| 10 | $ 2.04 | |||
| 25 | $ 1.85 | |||
| 50 | $ 1.72 | |||
| 100 | $ 1.60 | |||
| 500 | $ 1.35 | |||
| 1000 | $ 1.25 | |||
| Tape & Reel (TR) | 3000 | $ 1.12 | ||
| 6000 | $ 1.04 | |||
| 9000 | $ 1.00 | |||
Description
General part information
CT310LS-ID8
Magnetoresistive Sensor Angle, Rotary External Magnet, Not Included Gull Wing
