Description
General part information
KSF-R 25A 1000V (PF)
25A 1 kVDC Fuse Cartridge Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | KSF-R 25A 1000V (PF) |
|---|---|
| Applications | Solar (Photovoltaic) |
| Approval Agency | cULus |
| Breaking Capacity | 20 kA |
| Class | gPV |
| Current Rating | 25 A |
| DC Cold Resistance | 0.00396 Ohms |
| Fuse Type | Cartridge |
| Melting I²t | 1202 |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial Bend Cylinder |
| Response Time | Fast Blow |
| Size / Dimension Diameter | 0.406 in |
| Size / Dimension Length | 1.496 in |
| Voltage Rating - DC | 1 kV |
