APSDM008GD2AN-PTM1
ActiveApacer Memory America
SSD 8GB SATA DOM MLC SATAIII 5V
APSDM008GD2AN-PTM1
ActiveApacer Memory America
SSD 8GB SATA DOM MLC SATAIII 5V
Description
General part information
APSDM008GD2AN-PTM1
Solid State Drive (SSD) FLASH - NAND (MLC) 8GB SATA III Disk-On-Module, SATA DOM 5V
Technical Specifications
Parameters and characteristics for this part
| Specification | APSDM008GD2AN-PTM1 |
|---|---|
| Current - Max | 155 mA |
| Form Factor | SATA DOM, Disk-On-Module |
| Memory Size | 64 GBIT |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (MLC) |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Size / Dimension Height | 15.2 mm |
| Size / Dimension Length | 30 mm |
| Size / Dimension Width | 20 mm |
| Speed - Read | 105 MB/s |
| Speed - Write | 24 MB/s |
| Type | SATA III |
| Voltage - Supply | 5 VDC |
