Description
General part information
GFE240064E-BNFE-D
Graphic LCD Display Module Reflective FSTN - Film Super-Twisted Nematic Parallel
Technical Specifications
Parameters and characteristics for this part
| Specification | GFE240064E-BNFE-D |
|---|---|
| Background Color | Gray |
| Backlight | Without Backlight |
| Controller Type | NT7066U-F00 |
| Display Mode | Reflective |
| Display Type | FSTN - Film Super-Twisted Nematic |
| Dot Pitch Height | 0.7 mm |
| Dot Pitch Width | 0.6 mm |
| Dot Size Height | 0.65 mm |
| Dot Size Width | 0.55 mm |
| Interface | Parallel |
| Viewing Area Height | 16 mm |
| Viewing Area Width | 66 mm |
