Specification	NTE2930

Current - Continuous Drain (Id) (Tc)	31 A
Drain to Source Voltage (Vdss)	100 V
Drive Voltage (Max Rds On, Min Rds On)	10 V
FET Type	N-Channel
Gate Charge (Max)	97 nC
Input Capacitance (Ciss) (Max)	2270 pF
Mounting Type	Through Hole
Operating Temperature (Max)	175 °C
Operating Temperature (Min)	-55 °C
Package / Case	TO-3P-3 Full Pack
Package Name	TO-3PML
Power Dissipation (Max)	100 W
Rds On (Max)	40 mOhm
Technology	MOSFET (Metal Oxide)
Vgs (Max)	20 V
Vgs(th) (Max)	4 V

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources

No documents available
