PRN.000.025-0002

Active

Perinet

SBC 1.0GHZ 1 CORE 1GB RAM

Search across all available documentation for this part.

Active

Perinet

SBC 1.0GHZ 1 CORE 1GB RAM

Technical Specifications

Parameters and characteristics for this part

Part	RAM Capacity/Installed	Digital I/O Lines	Storage Interface	Operating Temperature [Min]	Operating Temperature [Max]	Power (Watts)	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Speed	Core Processor	Ethernet	USB	Number of Cores	USB [custom]
Perinet PRN.000.025-0007	1 GB	10	eMMC SD	-25 °C	75 °C	15 W	86.36 mm	132.08 mm	5.2 in	3.4 in	1 GHz	TI AM3352 ARM Cortex-A8 ARMv7	100 Mbps	USB 2.0 (1)	1
Perinet PRN.000.025-0011	1 GB	10	eMMC SD	-25 °C	75 °C	15 W	86 mm	132 mm	5.197 in	3.386 in	1 GHz	TI AM3352 ARM Cortex-A8 ARMv7	100 Mbps	USB 2.0 (1)	1
Perinet PRN.000.025-0002	1 GB	10	eMMC SD	-25 °C	75 °C	15 W	86.36 mm	132.08 mm	5.2 in	3.4 in	1 GHz	TI AM3352 ARM Cortex-A8 ARMv7	100 Mbps	USB 2.0 (1)	1
Perinet PRN.000.025-0006	1 GB	10	eMMC SD	-25 °C	75 °C	15 W	86.36 mm	132.08 mm	5.2 in	3.4 in	1 GHz	TI AM3352 ARM Cortex-A8 ARMv7	100 Mbps	USB 2.0 (1)	1
Perinet PRN.000.025-0008	2 GB	10	eMMC SD	-25 °C	75 °C	15 W	86.36 mm	132.08 mm	5.2 in	3.4 in		Marvell Armada 385 ARM Cortex-A9 ARMv7	100 Mbps		2	USB 2.0 (1) USB 3.0 (1)
Perinet PRN.000.025-0009	2 GB	10	eMMC SD	-25 °C	75 °C	15 W	86.36 mm	132.08 mm	5.2 in	3.4 in		Marvell Armada 385 ARM Cortex-A9 ARMv7	100 Mbps		2	USB 2.0 (1) USB 3.0 (1)
Perinet PRN.000.025-0012	2 GB	10	eMMC SD	-25 °C	75 °C	15 W	86 mm	132 mm	5.197 in	3.386 in		Marvell Armada 385 ARM Cortex-A9 ARMv7	100 Mbps		2	USB 2.0 (1) USB 3.0 (1)
Perinet PRN.000.025-0010	1 GB	10	eMMC SD	-25 °C	75 °C	15 W	86 mm	132 mm	5.197 in	3.386 in	1 GHz	TI AM3352 ARM Cortex-A8 ARMv7	100 Mbps	USB 2.0 (1)	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 651.81

General part information

Single Board Computer 1GHz 1 Core 1GB RAM TI AM3352 ARM Cortex-A8, ARMv7

Technical documentation and resources
