Description
General part information
CPEA3231L-100MC
10 µH Shielded Wirewound Inductor 55 A 1.06mOhm Max Vertical, 2 PC Pin
Technical Specifications
Parameters and characteristics for this part
| Specification | CPEA3231L-100MC |
|---|---|
| Current - Saturation (Isat) | 39 A |
| Current Rating | 55 A |
| DC Resistance (DCR) (Max) | 1.06 mOhm |
| Height - Seated (Max) | 1.201 in |
| Inductance | 10 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal Composite |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2 PC Pin, Vertical |
| Shielding | Shielded |
| Size / Dimension Length | 1.268 in |
| Size / Dimension Width | 1.24 in |
| Tolerance | 20 % |
| Type | Wirewound |
