S-1455CS
ActiveCentury Spring Corp
COMP O= .375,L= .81,W= .037
S-1455CS
ActiveCentury Spring Corp
COMP O= .375,L= .81,W= .037
Description
General part information
S-1455CS
COMP O= .375,L= .81,W= .037
Technical Specifications
Parameters and characteristics for this part
| Specification | S-1455CS |
|---|---|
| Diameter - Inside | 0.301 in |
| Diameter - Outside | 0.375 in |
| End Style | Ground, Closed |
| Finish | None |
| Free Length | 0.81 in |
| Material | Stainless Steel |
| Rate (lbs/in) | 7.8 lbs/in |
| Type | Compression |
| Wire Diameter | 0.037 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
