Molex

FCT STANDARD-DENSITY D-SUB CONNECTOR, MALE, STRAIGHT, PCB THROUGH HOLE, 17.10MM TAIL LENGTH, GOLD PLATING, 500 MATING CYCLES, 13.20MM SNAP-IN BOLT, 6.20MM FEMALE SCREW LOCK, 9 CIRCUITS, HEAT RESISTANT NATURAL INSULATOR

Find alt
1731091652

1731091652

Active
Molex

FCT STANDARD-DENSITY D-SUB CONNECTOR, MALE, STRAIGHT, PCB THROUGH HOLE, 17.10MM TAIL LENGTH, GOLD PLATING, 500 MATING CYCLES, 13.20MM SNAP-IN BOLT, 6.20MM FEMALE SCREW LOCK, 9 CIRCUITS, HEAT RESISTANT NATURAL INSULATOR

Find alt

Description

General part information

173109 Series

FCT Standard-Density D-Sub Connector, Male, Straight, PCB Through Hole, 10.30mm Tail Length, Gold Plating, 200 Mating Cycles, 6.30mm #4-40 Front Spacer, 6.50mm M3 Rear Spacer, 15 Circuits, White Insulator

Technical Specifications

Parameters and characteristics for this part

Specification1731091652
Connector LayoutDE, E
Connector StyleD-Sub
Connector TypeMale Pins, Plug
Contact FinishGold
Contact TypeSignal
Current Rating7.5 A
FeaturesGrounding Indents, Board Lock
FinishTin Plated
Flange FeatureFemale Screwlock (4-40), Mating Side
Ingress ProtectionIP20
Mounting TypeThrough Hole
Number of Positions9
Number of Rows2
Primary MaterialMetal
Shell MaterialSteel
Shell Size1
TerminationSolder
