1714H-60.000G33DTSTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
OSC,9*14, 60MHZ, HCMOS, 3.3V,50
1714H-60.000G33DTSTK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
OSC,9*14, 60MHZ, HCMOS, 3.3V,50
Description
General part information
1714H-60.000G33DTSTK
Oscillator
Technical Specifications
Parameters and characteristics for this part
| Specification | 1714H-60.000G33DTSTK |
|---|---|
| Base Resonator | Crystal |
| Frequency | 60 MHz |
| Frequency Stability | 30 ppm, 500 ppm |
| Function | Enable, Disable |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | HCMOS |
| Package / Case | No Lead, 6-SMD |
| Size / Dimension Length | 0.551 in, 0.354 in |
| Size / Dimension Width | 0.354 in |
| Type | XO (Standard) |
| Voltage - Supply | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
