SV 30

Active

LUMBERG

DIN AUDIO / VIDEO CONNECTOR, 3 CONTACTS, PLUG, PANEL MOUNT, SOLDER

Search across all available documentation for this part.

Active

LUMBERG

DIN AUDIO / VIDEO CONNECTOR, 3 CONTACTS, PLUG, PANEL MOUNT, SOLDER

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

3 Position Circular Connector Plug, Male Pins Solder

Technical documentation and resources

Parameters and characteristics commom to parts in this series

Specification	SV 30	- Series

Accessory Type	-	Cap (Cover), Protective, Wrench
Color	Silver	Silver
Connector Type	Plug, Male Pins	Plug, Male Pins
Contact Finish - Mating	Silver, Gold	Silver, Gold
Features	-	Strain Relief, Chain, M16, Ground Contact
For Use With/Related Products	-	03 Series Plug
Ingress Protection	IP40	IP40, IP68
Material Flammability Rating	UL94	UL94
Mounting Type	Free Hanging (In-Line), Cable Mount	Free Hanging (In-Line), Cable Mount
Number of Positions	-	4 - 8
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Primary Material	Metal	Metal
Shell Finish	Nickel	Nickel, Tin
Shell Material	Zinc Alloy	Zinc Alloy
Shell Size - Insert	M16	M16
Termination	Solder	Solder

CONNECTOR ACCESSORY, SLIT NUT, CIRCULAR CONNECTORS

Part	Operating Temperature [Max]	Operating Temperature [Min]	Shell Finish	Shell Material	Primary Material	Shell Size - Insert	Ingress Protection	Mounting Type	Number of Positions	Color	Termination	Connector Type	Material Flammability Rating	Contact Finish - Mating	Features	For Use With/Related Products	Accessory Type
LUMBERG 0385	85 °C	-40 °C	Nickel	Zinc Alloy	Metal	M16
LUMBERG KV 60	85 °C	-40 °C	Nickel	Zinc Alloy	Metal	M16	IP40	Cable Mount, Free Hanging (In-Line)	6	Silver	Solder	Male Pins, Plug	UL94	Gold, Silver	Strain Relief
LUMBERG SV 71	85 °C	-40 °C	Nickel	Zinc Alloy	Metal	M16	IP40	Cable Mount, Free Hanging (In-Line)	7	Silver	Solder	Male Pins, Plug	UL94	Gold, Silver	Strain Relief
LUMBERG 0381						M16				Silver						03 Series Plug	Cap (Cover), Protective
LUMBERG SV 80	85 °C	-40 °C	Nickel	Zinc Alloy	Metal	M16	IP40	Cable Mount, Free Hanging (In-Line)	8	Silver	Solder	Male Pins, Plug	UL94	Gold, Silver	Strain Relief
LUMBERG 0383						M16				Silver					Chain	03 Series Plug	Cap (Cover), Protective
LUMBERG KV 70	85 °C	-40 °C	Nickel	Zinc Alloy	Metal	M16	IP40	Cable Mount, Free Hanging (In-Line)	7	Silver	Solder	Male Pins, Plug	UL94	Gold, Silver	Strain Relief
LUMBERG KV 80	85 °C	-40 °C	Nickel	Zinc Alloy	Metal	M16	IP40	Cable Mount, Free Hanging (In-Line)	8	Silver	Solder	Male Pins, Plug	UL94	Gold, Silver	Strain Relief
LUMBERG SV 81	85 °C	-40 °C	Nickel	Zinc Alloy	Metal	M16	IP40	Cable Mount, Free Hanging (In-Line)	8	Silver	Solder	Male Pins, Plug	UL94	Gold, Silver	Strain Relief
LUMBERG SV 70	85 °C	-40 °C	Nickel	Zinc Alloy	Metal	M16	IP40	Cable Mount, Free Hanging (In-Line)	7	Silver	Solder	Male Pins, Plug	UL94	Gold, Silver	Strain Relief
