Specification	1751710

Color	Gray
Contact Mating Finish	Gold
Current - IEC	8 A
Mounting Type	Free Hanging (In-Line)
Number of Levels	1
Number of Positions	4
Pitch	0.138 in
Plug Wire Entry Angle	180 °
Positions Per Level	4
Termination Style	Tension Clamp, Screwless - Spring Cage
Type	Card Edge, Plug
Voltage - IEC	160 V
Wire Gauge or Range - AWG (Max)	25.5 AWG
Wire Gauge or Range - AWG (Min)	16 AWG
Wire Gauge or Range - mm² (Maximum)	1 mm²
Wire Gauge or Range - mm² (Minimum)	0.2 mm²
