Specification	WFK06123L000FE66

Composition	Metal Foil
Features	Current Sense, Anti-Sulfur, Automotive AEC-Q200
Height - Seated (Max)	0.028 in
Number of Terminations	4
Operating Temperature (Max)	170 °C
Operating Temperature (Min)	-55 °C
Package / Case	0612, Wide 1206 (3216 Metric)
Package Name	0612
Power (Watts)	1 W
Resistance	3 mOhms
Size / Dimension Length	0.122 in
Size / Dimension Width	0.063 in
Supplier Device Package	0612
Temperature Coefficient	150 ppm/¯C
Tolerance	1 %
