CFM-6020S-030-257
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 60X20MM 5VDC WIRE
CFM-6020S-030-257
ActiveSame Sky (Formerly CUI Devices)
FAN AXIAL 60X20MM 5VDC WIRE
Description
General part information
CFM-6020S-030-257
Fan Tubeaxial 5VDC Square - 60mm L x 60mm H Sleeve 11.4 CFM (0.319mł/min) 2 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | CFM-6020S-030-257 |
|---|---|
| Air Flow | 11.4 CFM |
| Approval Agency | cURus, TUV, CE |
| Bearing Type | Sleeve |
| Current Rating | 140 mA |
| Fan Type | Tubeaxial |
| Features | Auto Restart |
| Lifetime | 40000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 25.7 dB |
| Operating Temperature (Max) | 158 °F |
| Operating Temperature (Min) | 14 °F |
| Power (Watts) | 700 mW |
| RPM | 3000 RPM |
| Size / Dimension Height | 60 mm |
| Size / Dimension Length | 60 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.06 in H2O |
| Termination | 2 Wire Leads |
| Termination Leads Count | 2 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 5 VAC |
| Voltage Range (Max) | 13.2 VDC |
| Voltage Range (Min) | 10.8 VDC |
| Width | 20 mm |
