9001KP1LGG9
ActiveSCHNEIDER ELECTRIC
LED PANEL MOUNT INDICATOR, ROUND, SCREW CLAMP TERMINALS, GREEN, 120 VAC, 30 MM
9001KP1LGG9
ActiveSCHNEIDER ELECTRIC
LED PANEL MOUNT INDICATOR, ROUND, SCREW CLAMP TERMINALS, GREEN, 120 VAC, 30 MM
Description
General part information
9001KP1LGG9
LED Panel Indicator Green 110V ~ 120V Screw Terminal
Technical Specifications
Parameters and characteristics for this part
| Specification | 9001KP1LGG9 |
|---|---|
| Ingress Protection | 2, 6, IP66, 1, 13, 4, 3, NEMA 3R, 12 |
| Lamp Color | Green |
| Lens Color | Green |
| Panel Cutout Dimension | 1.18 " |
| Panel Cutout Shape | Round |
| Ratings | AC |
| Termination Style | Screw Terminal |
| Type | LED |
| Voltage (Max) | 120 V |
| Voltage (Min) | 110 V |
