8502 0181000

Active

Belden Inc.

HOOKUP STRND 20AWG WHT/BLU

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsCabling Solutions for Industrial Applications Datasheet

8502 0181000

Active

Belden Inc.

HOOKUP STRND 20AWG WHT/BLU

Deep-Dive with AI

DocumentsCabling Solutions for Industrial Applications Datasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	8502 0181000

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	28
Conductor Strand [custom]	7
Jacket (Insulation) Diameter [diameter]	0.058 in
Jacket (Insulation) Diameter [diameter]	1.47 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.25 mm
Jacket (Insulation) Thickness	0.01 in
Jacket Color	White, Blue Stripe
Length	1000 ft
Length	304.8 m
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Qualification	MIL-W-16878/1 Type B
Voltage	600 V
Wire Gauge	20 AWG

8502 Series

Part	Conductor Material	Jacket Color	Cable Type	Qualification	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Strand [custom]	Conductor Strand [custom]	Voltage	Wire Gauge	Length	Length	Operating Temperature [Min]	Operating Temperature [Max]	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]
Belden Inc. 8502 0181000	Copper Tinned	White Blue Stripe	Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG	1000 ft	304.8 m	-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm
Belden Inc. 8502 005100	Copper Tinned	Green	Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG			-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm	30.5 m	100 ft
Belden Inc. 8502 0091000	Copper Tinned		Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG	1000 ft	304.8 m	-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm
Belden Inc. 8502 007100	Copper Tinned	Violet	Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG			-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm	30.5 m	100 ft
Belden Inc. 8502 0061000	Copper Tinned	Blue	Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG	1000 ft	304.8 m	-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm
Belden Inc. 8502 002100	Copper Tinned	Red	Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG			-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm	30.5 m	100 ft
Belden Inc. 8502 003100	Copper Tinned	Orange	Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG			-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm	30.5 m	100 ft
Belden Inc. 8502 004100	Copper Tinned	Yellow	Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG			-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm	30.5 m	100 ft
Belden Inc. 8502 006100	Copper Tinned	Blue	Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG			-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm	30.5 m	100 ft
Belden Inc. 8502 010100	Copper Tinned	Black	Hook-Up	MIL-W-16878/1 Type B	0.25 mm	0.01 in	28	7	600 V	20 AWG			-40 °C	105 ░C	Poly-Vinyl Chloride (PVC)	0.058 in	1.47 mm	30.5 m	100 ft

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

8502 Series

20 AWG Hook-Up Wire 7/28 White, Blue Stripe 600V 1000.0' (304.8m)

Documents

Technical documentation and resources

Cabling Solutions for Industrial Applications

Datasheet
