Specification	SN471M035ST

Applications	General Purpose
Capacitance	470 µF
ESR (Equivalent Series Resistance)	400 mOhm
Height - Seated (Max)	1.26 in
Lead Spacing	0.295 in
Lifetime	1000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can, Radial
Polarization	Bi-Polar
Ripple Current	820 mA
Size / Dimension Diameter	0.63 in
Tolerance	20 %
Voltage - Rated	35 V
