HR-D
UnknownFDK America, Inc.
BATTERY NIMH 1.2V 6.5AH D
HR-D
UnknownFDK America, Inc.
BATTERY NIMH 1.2V 6.5AH D
Description
General part information
HR-D
D 1.2 V Nickel Metal Hydride Battery Rechargeable (Secondary) 6.5Ah
Technical Specifications
Parameters and characteristics for this part
| Specification | HR-D |
|---|---|
| Battery Cell Size | D |
| Battery Chemistry | Nickel Metal Hydride |
| Capacity (Charge) | 6.5 Ah |
| Discharge Rate (Current) | 1.3 A |
| Size / Dimension Diameter | 1.34 in |
| Size / Dimension Height | 2.33 in |
| Standard Charge Current | 730 mA |
| Standard Charge Time | 16 Hrs |
| Termination Style | Flat Top (Non-Extending) |
| Voltage - Rated | 1.2 VAC |
| Weight | 175.09 g |
