Specification	XUAH0515

Adjustment Type	Adjustable
Cable Length	78.74 in
Connection Method	Cable
Ingress Protection	IP65
Light Source	Yellow LED
Operating Temperature (Max)	55 °C
Operating Temperature (Min)	-25 °C
Output Configuration	PNP-NO
Response Time	500 µs
Sensing Distance	1.969 "
Sensing Method	Diffuse
Voltage - Supply (Maximum)	24 VAC
Voltage - Supply (Minimum)	12 VDC

osisense Series

Part	Indicator	Material - Body	Package / Case	Output Type	Sensor Type	Ingress Protection	Termination Style	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Shielding	Operating Temperature (Max)	Operating Temperature (Min)	Sensing Distance	Light Source	Connection Method	Sensing Method	Output Configuration	Cable Length
SCHNEIDER ELECTRIC XS530BLPAL2	LED	Nickel-Plated Brass	Cylinder Threaded - M30	3-Wire NO	Inductive	IP68	Cable	12 VDC	48 VDC	Unshielded	70 °C	-25 °C	0.394 "
SCHNEIDER ELECTRIC XUK0AKSAL2T						IP65		12 VDC	24 VAC		55 °C	-25 °C	98.43 '	Infrared	Cable	Through-Beam	NO NPN-NC	78.74 in
SCHNEIDER ELECTRIC XS630B1NAL2	LED	Nickel-Plated Brass	Cylinder Threaded - M30	3-Wire NPN-NO	Inductive	IP68 IP69K	Cable Leads	12 VDC	48 VDC	Unshielded	70 °C	-25 °C	0.591 "
SCHNEIDER ELECTRIC XUB0SPSNL2						IP65		12 VDC	24 VAC		55 °C	-25 °C	787.402 "	Infrared	Cable		NO PNP-NC	78.74 in
SCHNEIDER ELECTRIC XS512B1DAM12	LED	Nickel-Plated Brass	Cylinder Threaded - M12	2-Wire NO	Inductive	IP67 IP69K	Connector	12 VDC	48 VDC	Unshielded	70 °C	-25 °C	0.079 "
SCHNEIDER ELECTRIC XS530B1DAM12	LED	Nickel-Plated Brass	Cylinder Threaded - M30	2-Wire NO	Inductive	IP67	Connector	12 VDC	48 VDC	Unshielded	70 °C	-25 °C	0.394 "
SCHNEIDER ELECTRIC XS508B1NAM8	LED	Metal	Cylinder Threaded - M8	3-Wire NPN-NO	Inductive	IP67	Connector	12 VDC	24 VAC	Shielded	70 °C	-25 °C	0.059 "
SCHNEIDER ELECTRIC XS530B1NAM12	LED	Nickel-Plated Brass	Cylinder Threaded - M30	3-Wire NPN-NO	Inductive	IP67	Connector	12 VDC	24 VAC	Unshielded	70 °C	-25 °C	0.394 "
SCHNEIDER ELECTRIC XS518B1NAL2	LED	Nickel-Plated Brass	Cylinder Threaded - M18	3-Wire NPN-NO	Inductive	IP68 IP69K	Cable Leads	12 VDC	24 VAC	Unshielded	70 °C	-25 °C	0.197 "
SCHNEIDER ELECTRIC XS508B1DAM12	LED	Stainless Steel	Cylinder Threaded - M8	2-Wire NO	Inductive	IP67	Connector	12 VDC	48 VDC	Unshielded	70 °C	-25 °C	0.059 "
