Specification	9007AW46

Actuator Type	Top Rotary, Adjustable Rod
Circuit	SPDT-DB
Current Rating	0.5 A, 15 A
Ingress Protection Description	Dust Tight, Water Resistant
Ingress Protection IP Rating	IP65
Mounting Type	Chassis Mount
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-18 °C
Switch Function	On-Mom
Termination Style	Screw Terminal
Voltage Rating - AC	120 V
Voltage Rating - DC	125 V
