MSP06C0333R0GEJ
ActiveVishay Dale
RES ARRAY 3 RES 33 OHM 6SIP
MSP06C0333R0GEJ
ActiveVishay Dale
RES ARRAY 3 RES 33 OHM 6SIP
Description
General part information
MSP06C0333R0GEJ
33 Ohm ±2% 400mW Power Per Element Isolated 3 Resistor Network/Array ±100ppm/°C 6-SIP
Technical Specifications
Parameters and characteristics for this part
| Specification | MSP06C0333R0GEJ |
|---|---|
| Circuit Type | Isolated |
| Height - Seated (Max) | 0.195 in |
| Mounting Type | Through Hole |
| Number of Pins | 6 pins |
| Number of Resistors | 3 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 6-SIP |
| Package Name | 6-SIP |
| Power Per Element | 400 mW |
| Resistance | 33 Ohms |
| Resistor Ratio Drift | 50 ppm/°C |
| Size / Dimension Length | 0.59 in |
| Size / Dimension Width | 0.09 in |
| Temperature Coefficient | 100 ppm/°C |
| Tolerance | 2 % |
