474159-E
ActiveTE Connectivity AMP Connectors
SRCP 1,27 4 F 1-KS IDC22 137 E1 162 1,27
474159-E
ActiveTE Connectivity AMP Connectors
SRCP 1,27 4 F 1-KS IDC22 137 E1 162 1,27
Description
General part information
474159-E
Connector Assembly, Receptacle, Cable-to-Board, 4 Position, 1.27 mm [.05 in] Centerline, Insulation Displacement (IDC), 1 Row, Black, Wire & Cable
Technical Specifications
Parameters and characteristics for this part
| Specification | 474159-E |
|---|---|
| Cable Termination | IDC |
| Color | Black |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Fastening Type | Push-Pull |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Pitch | 0.05 in |
| Wire Gauge | 22 AWG |
| Wire Type | Discrete |
