60470-1
ActiveTE Connectivity AMP Connectors
SPLC 3300-9000 ROHS COMPLIANT: YES
60470-1
ActiveTE Connectivity AMP Connectors
SPLC 3300-9000 ROHS COMPLIANT: YES
Description
General part information
60470-1
Pigtail Splice / Thru Splice, Serrated, 3300 – 9000 CMA, Steel, 3 Serration, 3.86 mm [.152 in] Length, Reel, Open Barrel, SPLICE
Technical Specifications
Parameters and characteristics for this part
| Specification | 60470-1 |
|---|---|
| Features | Ridged |
| Insulation | Non-Insulated |
| Number of Wire Entries | Varies by Wire Size |
| Terminal Type | Open Band, Crimpband |
| Termination | Crimp |
| Wire Gauge (CMA) (Max) | 9000 CMA |
| Wire Gauge (CMA) (Min) | 3300 CMA |
