11914CS
ActiveCentury Spring Corp
COMP O=1.406,L= 4.00,W= .088
11914CS
ActiveCentury Spring Corp
COMP O=1.406,L= 4.00,W= .088
Description
General part information
11914CS
COMP O=1.406,L= 4.00,W= .088
Technical Specifications
Parameters and characteristics for this part
| Specification | 11914CS |
|---|---|
| Diameter - Inside | 1.23 in |
| Diameter - Outside | 1.406 in |
| End Style | Ground, Closed |
| Finish | None |
| Free Length | 4 in |
| Material | Stainless Steel |
| Rate (lbs/in) | 4.8 lbs/in |
| Type | Compression |
| Wire Diameter | 0.088 in |
