ADCM-S06R0SA105RB
ActiveAbracon LLC
CAPACITOR 1F 6V TH
ADCM-S06R0SA105RB
ActiveAbracon LLC
CAPACITOR 1F 6V TH
Description
General part information
ADCM-S06R0SA105RB
1 F (EDLC) Supercapacitor 6 V Radial 720mOhm @ 1kHz
Technical Specifications
Parameters and characteristics for this part
| Specification | ADCM-S06R0SA105RB |
|---|---|
| Capacitance | 1 F |
| ESR (Equivalent Series Resistance) | 720 mOhm |
| Height - Seated (Max) | 0.63 in |
| Lead Spacing | 0.472 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 65 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial |
| Size / Dimension Length | 0.65 in |
| Size / Dimension Width | 0.335 in |
| Termination | PC Pins |
| Tolerance (Negative) | 0 % |
| Tolerance (Positive) | 30 % |
| Voltage - Rated | 6 VDC |
