Description
General part information
WPS400-8020L
0 ~ 80V Output Bench (AC to DC) Power Supply VFD 0 ~ 20A Output 400W Features List Output, Programmable, RS232, RS485, SENSE, Temperature Monitoring, USB, Wide Range
Technical Specifications
Parameters and characteristics for this part
| Specification | WPS400-8020L |
|---|---|
| Accuracy - Ammeter (Absolute) | 0.01 A |
| Accuracy - Ammeter (Percent) | 0.1 % |
| Accuracy - Voltmeter (Absolute) | 5 mV |
| Accuracy - Voltmeter (Percent) | 0.03 % |
| Current - Output (Max) | 20 A |
| Current - Output (Min) | 0 A |
| Current Regulation - Line (Absolute) | 6 mA |
| Current Regulation - Line (Percentage) | 0.05 % |
| Current Regulation - Load (Absolute) | 6 mA |
| Current Regulation - Load (Percentage) | 0.05 % |
| Display Type | VFD |
| Features | List Output, Programmable, Wide Range, SENSE, Temperature Monitoring, RS485, RS232, USB |
| Number of Characters | 5 characters |
| Number of Outputs | 1 |
| Power (Watts) | 400 W |
| Ripple Current (RMS) | 8 mA |
| Ripple Voltage (RMS) | 8 mV |
| Size / Dimension Height | 4.331 in |
| Size / Dimension Length | 18.701 in |
| Size / Dimension Width | 10.039 in |
| Type | Bench (AC to DC) |
| Voltage - Output (Max) | 80 V |
| Voltage - Output (Min) | 0 V |
| Voltage - Supply | 220 VAC, 110 VAC |
| Voltage - Supply | 220VAC, 110VAC |
| Voltage - Supply (Option 1) | 110 VAC |
| Voltage - Supply (Option 2) | 220 VAC |
| Voltage Regulation - Line (Absolute) | 30 mV |
| Voltage Regulation - Line (Percentage) | 0.01 % |
| Voltage Regulation - Load (Percentage) | 0.01 % |
| Voltage Regulation - Load (Voltage Offset) | 30 mV |
| Weight | 28.7 lbs |
