SRP5020C-2R2M
ObsoleteBourns Inc.
FIXED IND 2.2UH 5.5A 41 MOHM SMD
SRP5020C-2R2M
ObsoleteBourns Inc.
FIXED IND 2.2UH 5.5A 41 MOHM SMD
Description
General part information
SRP5020C-2R2M
2.2 µH Shielded Inductor 5.5 A 41mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | SRP5020C-2R2M |
|---|---|
| Current - Saturation (Isat) | 8.8 A |
| Current Rating | 5.5 A |
| DC Resistance (DCR) (Max) | 41 mOhm |
| Frequency - Self Resonant | 40 MHz |
| Height - Seated (Max) | 0.079 in |
| Inductance | 2.2 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Q | 20 |
| Shielding | Shielded |
| Size / Dimension Length | 0.224 in |
| Size / Dimension Width | 0.205 in |
| Tolerance | 20 % |
