34134
ActiveTE Connectivity AMP Connectors
CONN INLINE 14-16 AWG CRIMP
34134
ActiveTE Connectivity AMP Connectors
CONN INLINE 14-16 AWG CRIMP
Description
General part information
34134
Parallel Splice, 16 – 14 AWG, 1.25 – 2 mm² Wire, Serrated, 2050 – 5180 CMA, Copper, Blue, 19.3 mm [.76 in] Length, Loose Piece, PLASTI-GRIP
Technical Specifications
Parameters and characteristics for this part
| Specification | 34134 |
|---|---|
| Color | Blue |
| Features | Serrated Mating Area |
| Insulation | Fully Insulated |
| Number of Wire Entries | 2 |
| Terminal Type | Inline, Individual Openings (Parallel) |
| Termination | Crimp |
| Wire Gauge (AWG) (Max) | 16 AWG |
| Wire Gauge (AWG) (Min) | 14 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
PLASTI-GRIP INSULATED BUTT SPLICES, TERMNAL SPLICES AND TERMINALS REPORT
PLASTI GRIP Terminals and Splices
Plastic-Grip terminals
Datasheet
Plastic-Grip and Solistrand terminal, butt and parallel connectors
WIRE CONN, TERMINALS, BUTT AND PARALLEL CONNECTORS-PLASTI-GRIP, SOLISTRAND, STD B, DIAMOND GRIP, PIDG AND AMPOWER REPORT
Pressure Type Wire Connectors Wire Combinations PLASTI-GRIP Splices (Use Tooling for PLASTI-GRIP Splices)
ENG_CD_34134_D1.pdf
34134 | Datasheet
