Description
General part information
TEL0117
LoRa™ Transceiver Module 868MHz Whip, Straight Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | TEL0117 |
|---|---|
| Antenna Type | Straight, Whip |
| Current - Receiving | 20 mA |
| Current - Transmitting | 100 mA |
| Data Rate | 9.6 kBaud |
| Frequency | 868 MHz |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 7-SIP Module |
| Power - Output | 20 dBm |
| Protocol | LoRa™ |
| Sensitivity | -148 dBm |
| Serial Interfaces | Serial TTL |
| Utilized IC / Part | SX1276 |
| Voltage - Supply (Maximum) | 5 V |
| Voltage - Supply (Minimum) | 3.3 V |
