Description
General part information
09675159675
15 Position D-Sub Plug, Male Pins Connector
Technical Specifications
Parameters and characteristics for this part
| Specification | 09675159675 |
|---|---|
| Connector Layout | A, DA |
| Connector Style | D-Sub |
| Connector Type | Male Pins, Plug |
| Contact Finish | Gold-Palladium, Gold |
| Contact Finish Thickness | 30 µin |
| Contact Form | Machined |
| Contact Material | Copper Alloy |
| Contact Type | Signal |
| Current Rating | 5 A |
| Dielectric Material | Thermoplastic, Glass Filled |
| Features | Grounding Indents, Board Lock |
| Finish | Tin Plated |
| Flange Feature | Shell (M3), Housing |
| Ingress Protection Description | Waterproof, Dust Tight |
| Ingress Protection IP Rating | IP67 |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Panel Mount, Through Hole |
| Number of Positions | 15 |
| Number of Rows | 2 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -25 °C |
| Shell Material | Brass |
| Shell Size | 2 |
| Termination | Solder |
