Specification	B43268B5397M062

Applications	Automotive
Capacitance	390 µF
ESR (Equivalent Series Resistance)	170 mOhm
Height - Seated (Max)	1.476 in
Impedance	250 mOhms
Lead Spacing	0.394 in
Lifetime	3000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Package Leads	3 Leads
Package Name	Radial, Can - Snap-In
Polarization	Polar
Ratings	AEC-Q200
Ripple Current	1.84 A
Size / Dimension Diameter	1.378 in
Tolerance	20 %
Voltage - Rated	450 V
