Specification	XB4BL42

Actuator Type	Button, Round
Circuit	SPST-NC
Color - Actuator/Cap	Red
Current Rating	550 mA, 6 A
Electrical Life (Cycles)	1000000 Cycles
Ingress Protection Description	Waterproof, Water Resistant, Dust Tight
Ingress Protection IP Rating	IP69K, IP69, IP67, IP66
Mechanical Life (Cycles)	10000000 Cycles
Mounting Type	Front, Panel Mount
Operating Temperature (Max)	70 °C
Operating Temperature (Min)	-40 °C
Panel Cutout Diameter	22 mm
Panel Cutout Shape	Circular
Switch Function	Off-On
Termination Style	Screw Terminal
Type	Standard
Voltage Rating - AC	120 V
Voltage Rating - DC	125 V
