SCCV40E506SRBQ
ActiveKYOCERA AVX
50 F, 3.0VDC & 18M ESRDC
SCCV40E506SRBQ
ActiveKYOCERA AVX
50 F, 3.0VDC & 18M ESRDC
Description
General part information
SCCV40E506SRBQ
50 F (EDLC) Supercapacitor 3 V Radial, Can 18mOhm @ 1kHz 1000 Hrs @ 65°C
Technical Specifications
Parameters and characteristics for this part
| Specification | SCCV40E506SRBQ |
|---|---|
| Capacitance | 50 F |
| ESR (Equivalent Series Resistance) | 18 mOhm |
| Height - Seated (Max) | 1.654 in |
| Lead Spacing | 0.315 in |
| Lifetime | 1000 Hrs |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 65 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Can, Radial |
| Size / Dimension Diameter | 0.709 in |
| Termination | PC Pins |
| Tolerance (Negative) | 10 % |
| Tolerance (Positive) | 30 % |
| Voltage - Rated | 3 VDC |
