HW-04-09-F-S-293-SM
CONN BOARD STACKER HDR 4 POS 2.54MM SOLDER ST TOP ENTRY SMD LAYER
Technical Specifications
Parameters and characteristics for this part
| Specification | HW-04-09-F-S-293-SM |
|---|---|
| Color | Black |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | 3 µin |
| Length - Overall Pin | 0.665 in |
| Length - Post (Mating) | 0.372 in |
| Length - Stack Height | 0.293 in |
| Mounting Type | Surface Mount |
| Number of Positions | 4 |
| Number of Rows | 1 |
| Pitch | 0.1 in |
| Termination | Solder |
