OD1238-48HHB10AZX
ActiveORION FANS
48VDC 120X120X38MM REVERSIBLE FL
OD1238-48HHB10AZX
ActiveORION FANS
48VDC 120X120X38MM REVERSIBLE FL
Description
General part information
OD1238-48HHB10AZX
Fan Tubeaxial 48VDC Square - 120mm L x 120mm H Ball 146.0 CFM (4.09m³/min) 4 Wire Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | OD1238-48HHB10AZX |
|---|---|
| Air Flow | 146 CFM |
| Approval Agency | cURus, UR, CE, TUV |
| Bearing Type | Ball |
| Current Rating | 0.2 A |
| Fan Type | Tubeaxial |
| Features | Auto Restart, PWM Control, Reversible Flow, Speed Sensor (Tach) |
| Lifetime | 70000 Hrs |
| Material - Blade | PBT, Polybutylene Terephthalate |
| Material - Frame | Polybutylene Terephthalate (PBT) |
| Noise | 50 dB |
| Operating Temperature (Max) | 149 °F |
| Operating Temperature (Min) | 5 °F |
| Power (Watts) | 8.2 W |
| RPM | 3590 RPM |
| Size / Dimension Height | 120 mm |
| Size / Dimension Length | 120 mm |
| Size / Dimension Shape | Square |
| Static Pressure | 0.6 in H2O |
| Termination | 4 Wire Leads |
| Termination Leads Count | 4 leads |
| Termination Type | Wire Leads |
| Voltage - Rated | 48 VDC |
| Width | 38 mm |
