AK4091/1KD-4.0-WH-SMD
ActivePTR Hartmann
TERM BLK 1POS 4.0MM 0.157" PCB
AK4091/1KD-4.0-WH-SMD
ActivePTR Hartmann
TERM BLK 1POS 4.0MM 0.157" PCB
Description
General part information
AK4091/1KD-4.0-WH-SMD
1 Position Wire to Board Terminal Block Horizontal with Board Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | AK4091/1KD-4.0-WH-SMD |
|---|---|
| Color | White |
| Contact Material - Plating | Copper Alloy |
| Current | 9 A |
| Housing Material | Polyphthalamide, PPA |
| Mating Orientation | Horizontal with Board |
| Mounting Type | Surface Mount |
| Number of Levels | 1 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -60 °C |
| Positions Per Level | 1 |
| Voltage | 600 V |
| Wire Gauge (AWG) (Max) | 24 AWG |
| Wire Gauge (AWG) (Min) | 18 AWG |
| Wire Termination | Leg Spring, Screwless, Push-In Spring |
