PSC-48124
ObsoleteAltech Corporation
AC/DC DIN RAIL SUPPLY 24V 480W
PSC-48124
ObsoleteAltech Corporation
AC/DC DIN RAIL SUPPLY 24V 480W
Description
General part information
PSC-48124
AC/DC DIN RAIL SUPPLY 24V 480W
Technical Specifications
Parameters and characteristics for this part
| Specification | PSC-48124 |
|---|---|
| AC Voltage - Input (Max) | 264 VAC |
| AC Voltage - Input (Min) | 88 VAC |
| Applications | Industrial, ITE (Commercial) |
| Approval Agency | CE, TUV, cULus |
| Current - Output (Max) | 20 A |
| DC Voltage - Input (Max) | 373 V |
| DC Voltage - Input (Min) | 124 V |
| Efficiency | 93 % |
| Features | Universal Input, Remote On/Off, Adjustable Output, PFC |
| Input Type | AC or DC, DC, AC |
| Minimum Load Required | No |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -20 °C |
| Power (Watts) | 480 W |
| Size / Dimension Height | 4.91 in |
| Size / Dimension Length | 4.86 in |
| Size / Dimension Width | 3.4 in |
| Standard Number | 508, 60950-1 |
| Voltage - Isolation | 4242 V |
| Voltage - Output 1 | 24 V |
