Specification	CX2520DB38400H0FLJC1

ESR (Equivalent Series Resistance)	50 Ohm
Frequency	38.4 MHz
Frequency Stability	15 ppm
Frequency Tolerance	10 ppm
Height - Seated (Max)	0.022 in
Load Capacitance	12 pF
Mounting Type	Surface Mount
Operating Mode	Fundamental
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-30 °C
Package / Case	4-SMD, No Lead
Package Length	2.5 mm
Package Name	4-SMD
Package Width	2 mm
Size / Dimension Length	0.098 in
Size / Dimension Width	0.079 in
Type	MHz Crystal
