R12-2RS
ActiveMechatronics Bearing Group
BALL BEARING 0.75X1.625X0.4375
R12-2RS
ActiveMechatronics Bearing Group
BALL BEARING 0.75X1.625X0.4375
Description
General part information
R12-2RS
Ball Bearing 0.750" (19.05mm) 3/4" ID X 1.625" (41.28mm) OD X 0.438" (11.11mm) 7/16" W
Technical Specifications
Parameters and characteristics for this part
| Specification | R12-2RS |
|---|---|
| Dynamic Load Rating | 1265 lbs |
| Features | Contact Seal (2) |
| Inner Diameter | 0.75 in |
| Inner Diameter (Fraction) | 3/4" |
| Material | Bearing Steel |
| Outer Diameter | 1.625 in |
| Static Load Rating | 850 lbs |
| Type | Ball Bearing |
| Width | 0.438 in |
