Description
General part information
0015388029
SL FFC/FPC OPT D FEMALE TIN 2CKT
Technical Specifications
Parameters and characteristics for this part
| Specification | 0015388029 |
|---|---|
| Cable End Type | Straight |
| Connector/Contact Type | Receptacle |
| Contact Finish | Tin |
| Contact Material | Phosphor Bronze |
| FFC, FCB Thickness (Additional) | 0.3 mm |
| FFC, FCB Thickness (Max) | 0.28 mm |
| FFC, FCB Thickness (Min) | 0.13 mm |
| Flat Flex Type | FFC, FPC |
| Housing Material | Polyester, Glass Filled |
| Locking Feature | Latch Lock |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 2 |
| Operating Temperature (Max) | 105 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.1 in |
| Termination | IDC |
| Voltage Rating | 250 V |
