Description
General part information
XGL3520-301MEC
300 nH Shielded Molded Inductor 14.1 A 4.8mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | XGL3520-301MEC |
|---|---|
| Current - Saturation (Isat) | 9.7 A |
| Current Rating | 14.1 A |
| DC Resistance (DCR) (Max) | 4.8 mOhm |
| Frequency - Self Resonant | 165 MHz |
| Height - Seated (Max) | 0.079 in |
| Inductance | 300 nH |
| Inductance Frequency - Test | 1 MHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Size / Dimension Length | 0.138 in |
| Size / Dimension Width | 0.126 in |
| Tolerance | 20 % |
| Type | Molded |
